4ft Lighting Led Tubes Integrated T5

T5 LED Integrated Tube Light, is a complete set that was built together with the heatsink and build-in driver, is one of the normal and most popular tube types in the market, widely used in places like office, school, hospital, parking lot etc. T5 LED Integrated Tube Light is with all the sizes and power mode you need and at the same time more stable and with better reliability.



Product Features



1. With mounting bracket, easy for installation, and can help for shadowless connecting.

2. With ultra-high brightness SMD2835, with lifetime over 50000 hours, can save over 75% energy.

3. Built-in high precision constant current power supply, with efficiency high up to 90%. With protector, which can help to work under unstable voltage.

4. With Superior quality aluminum housing can help for better heat sink, and plastic cover can achieve high light luminousness, which all work on lengthen the service life and at the same time they are recyclable.

5. Special irritation angle mixed design. Special circuit design, can avoid depress because of single LED chip breakdown.

6. Immediately light up, no flicker, no noises；

7. Environment friendly, no mercury, no lead.



Data sheet of T5 LED Integrated Tube Light

Specification	T5 LED Integrated Tube Light
Product Model	T5-G30-6W	T5-G60-10W	T5-G90-14W	T5-G120-18W	T5-G150-25W
Wattage	6W	10W	14W	18W	25W
Dimensions	30CM	60CM	90CM	120CM	150CM
Lighting Source	SMD2835	SMD2835	SMD2835	SMD2835	SMD2835
SMD Qty.	30PCS	60PCS	90PCS	120PCS	144PCS
Power Factor	>0.95
Input Voltage	AC85-277V
Harmonic wave	≤20%
Energy Class	A++
CRI	>80
Beam Angle (Degree)	120°
Light Efficiency	130-180 lm/w  available
Color Temperature (K)	3000K 4000K 5000K 6500K
Working temperature	-20℃ to +40℃
Storage temperature	-20℃ to +55℃
Operating humidity	10% - 80%
Warranty	5 years



Except the shadowless connecting one, for T5 LED Integrated Tube Light, we have two other optional models, which just with a little bit different with the end cap and dimensions.



See picture showed below



Photomatric data and illumination diagram of T5 LED Integrated Tube Light



T5 LED Integrated Tube Light Packing Instruction

On the premise that the packaging is in compliance with relevant regulations and guidelines, our products can be more perfectly packaged according to your requirements. Our company can also provide related packaging solutions according to your order quantity, shipping method and product sales method. , Such as color box, white box, paper tube and other solutions for packaging, the following is our regular product packaging diagram and packing weight.







Light Victor production capacity

1) More than 50,000 pieces of LED tube light monthly

2) More than 5000 pieces of LED panel light monthly

3) More than 5000 pieces of LED Tri Proof light monthly

4) More than 5000 pieces of LED high bay light monthly



Light Victor tubes product warranty assurance

All our tube products are with 3 years or 5 years warranty that is mean, the period of the quality guarantee of the product is since the commissioning of qualified acceptance date of 36 months or 60 months after delivery.

The contract products within the warranty period under normal operation conditions and technical requirements of the bid is not in conformity with the specifications of the defect or fault, our side will responsible for the free replacement, repair and debugs.
